TSC series high efficiency high weight centricleaner

Contact Us

Categories: ,
Tags:

描述

TSC series high efficiency high weight centricleaner is a kind of forward item which uses centrifugal principle to remove reject from the pulp. It can be used in various pulp cleaning systems to remove heavy rejects such as sand, iron chips, dust and large ink particles. It can be combined with light weight cleaner according to different kinds of pulp to achieve ideal cleaning effect.

Key features:

A Parted structure: TSC centricleaner is designed to be a parted structure. The whole centricleaner can be divided into 3-4 sections, which is convenient for disassembly and replacement.

B Different ways of residue dicharge: This centricleaner can be chosen different residue discharge ways:pressure residue discharge and open residue discharge, to adapt to their working environment according to different needs of user.

Specification TSC-400 TSC-600 TSC-800 TSC-1000 TSC-1200
Feeding Flow (L/min) 380-450 600 800 1000 1200
Feeding Pressure (MPa) 0.3-0.4 0.3-0.4 0.3-0.4 0.3-0.4 0.3-0.4
Pressure Drop

(MPa)



0.14-0.18



0.14-0.18

0.14-0.18 0.14-0.18 0.14-0.18
Feeding Density(%) 0 -1.5 0-1.5 0-1.5 0-1.5 0-1.5
Mini Accept Pressure(MPa) 0.1 0.1 0.1 0.1 0.1
Max Tempt of Operating (℃) 80 80 80 80 80
