Description

TFK-500 centricleaner is a new generation of high-efficiency multifunctional item developed by Tianli Machinery on the basis of widely absorbing abroad advanced purification technology. The product adopts a professional entrance design with high surface finish, so that the discharging rate tends to be the lowest under high impurity removal efficiency, and the fiber loss is completely reduced. It is especially suitable for removing sand, dust, rust and other small heavy impurities in the pulp. TFK-500 multifunctional centricleaner has a professional design of inlet and outlet as well as the cone angle, which ensures that a stable vortex can be formed under a certain inlet pressure. Compared with the traditional centricleaners, it has obvious energy-saving effect and reduces the purification system maintenance costs.

Main Technical Data

Feeding flow: 500-600 L/min

Feeding pressure: 0.32-0.40 MPa

Press drop: 0.14 MPa

Volume reject removal rate: 10-15 % (relative to feeding flow)
